Dry-filter liquid paint booth
The dry-filter liquid paint booth uses replaceable filter cassettes instead of paper accordions. Cassettes are swapped from the front in minutes, which suits shops that paint every day and want short stops. Booth size, electrical load and lighting are set per project from the largest part.
| Filter | Dry filter cassettes |
|---|---|
| Size | Per project |
| Lighting | LED |
Technical data
The table shows the standard size. Values marked per project are set from your part and line and appear in the proposal, with the drawing for your size.
Quote for your dimensions| Filter | Dry filter cassettes |
|---|---|
| Booth size | Per project |
| Electrical load | Per project |
| Lighting | LED |
How we size it
As for the paper-filter booth: width and depth from the part and the spray distance, filter wall from the airflow. Cassette count follows the filter wall area; the spec table states the electrical load for each size.
What it is for
- Shops where paper filters would be replaced often
- Enclosed workshop layouts
Options
- Air make-up with heating
- Pass-through layout on a conveyor
- Explosion-proof lighting for solvent-based paints
Standards
ATEX-certified components in the classified zone; CE Declaration of Conformity supplied. Built to EN 16985:2018.
Values marked "Per project" in the table are set from your part and line, and appear in the proposal.
Quote for the dry-filter liquid paint booth
Send the part size, quantity and line speed; we reply within 2 working days.
